. SRT ROTOTILLERS OPERATORS MANUAL 7055 BRIGGS & stratton 4-cycle 206cc 8.50 ft-lbs gross torque 7065V VIPER ELECTRIC 4-cycle, 196 cc ARDISAM.com GetEarthquake.com OMSRT08 Rev. 1/18/08 © 2008 Ardisam, Inc. All Rights Reserved.
Printed in USA. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V INTRODUCTION Thank You. For purchasing an Earthquake® forward rotating rear-tine rototiller from Ardisam, Inc. We have worked to ensure that this rear-tine rototiller meets high standards for usability and durability.
With proper care, your rototiller will provide many years of service. Please take the time to read this manual carefully to learn how to correctly operate and maintain your rototiller. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V SAFETY! DANGER OWNER’S RESPONSIBILITY Accurate assembly and safe and effective use of the rototiller is the owner’s responsibility.
Read and follow all safety instructions. DANGER INDICATES a serious injury or fatality will result if the safety instructions that follow this signal word are not obeyed.
Carefully follow all assembly instructions. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V c. Fill fuel tank outdoors with extreme care. Never fill fuel tank indoors. Replace gasoline cap securely and clean up spilled fuel before restarting.
Never attempt to make any adjustments while the engine is running. Operation. Never operate the tiller without guards, covers, and hoods in place. Never start the engine or operate the tiller with the wheels in the free-wheel position. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V SAFETY DECALS This rototiller unit has been designed and manufactured to provide you with the safety and reliability you would expect from an industry leader in outdoor power equipment manufacturing. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Unpacking and Assembly Your rototiller comes fully assembled except for a few parts.
The following instructions will help you unpack your tiller and assemble and adjust your tiller’s depth regulator lever, cable tension and handlebar height. You will need 2- 9/16” wrenches.
Unpack tiller 1. Open top of carton and remove handlebar assembly. Find parts packet. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Features forward drive safety control lever reverse drive safety control lever forward & reverse cable bumper guard (optional) depth regulator lever detent pin belt guard wheel lock pin recoil start serial number plate 800-345-6007 Page GetEarthquake. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V OperatioN! CAUTION PRE-START INSPECTIOn 1.
Make sure all safety guards are in place and all nuts and bolts are secure. Check oil level in engine crankcase. See your engine manual for procedure and specifications. Inspect air cleaner for cleanliness. See your engine manual for procedure.
Check the fuel supply. Fill the fuel tank no closer than 1 inch from top of tank to provide space for expansion. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Idle Speed Use the “low” position on the throttle lever to reduce stress on the engine when tilling is not being performed. Lowering the engine speed to “idle” will help extend the life of the motor, as well as conserve fuel and reduce the noise level of the equipment. Operating Speed For normal tilling, set the throttle lever to “fast”. SHUTTING DOWN To stop the engine at any time, move throttle control to the off position. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Drive SAFETY Control LeverS!
CAUTION FORWARD LEVER Engages wheels and tines into forward. Pulling the drive safety control lever labeled (FORWARD) toward the handlebar engages the wheels and tines. Releasing the lever stops the wheels and tines and brings the tiller to a complete stop. Forward lever engaged Do not operate both “FORWARD” and “REVERSE” drive safety control levers at the same time. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Wheel Lock pins! WARNING Place wheels in tilling position. Remove lock pin.
Align hole in axle with hole in wheel hub. (SEE FIGURE 2) 2.
Insert lock pin through holes, fold lock pin ring to secure pin to axle. Firmly lock wheel and axle together before tilling.
Cancel the membership at any time if not satisfied. But if You are still not sure with the service, you can choose FREE Trial service. Note: We cannot guarantee that every book is in the library. 2018 polaris magnum 330 repair manual. You can cancel anytime.
Repeat for other wheel. Never start engine or operate tiller with wheels in free-wheel position. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V DEPTH REGULATOR LEVER Tilling depth is controlled by the height of the depth regulator lever. To adjust tilling depth.
(SEE FIGURE 4) 1. Remove detent pin. Raise the depth regulator lever to position tines at chosen tilling depth.
Align hole in depth regulator lever with hole in depth regulator bracket and replace detent pin. Depth Regulator Lever Down = Shallower tilling. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Tilling Tips The key to successful tilling is to begin with a shallow cut on the first pass, and then work an inch or two deeper on each successive pass. Tilling depth will vary with ground conditions.
When beginning to till in unbroken ground or in extremely hard soil, set the detent pin in the highest hole of the drag stake (follow instructions under Tilling section). This will allow for shallow tilling. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V MAINTENANCE MAINTENANCE SCHEDULE Your rototiller has been designed and produced by the industry’s leading manufacturer of outdoor power equipment to provide you with years of reliable operation.
Keeping your tiller in top running condition will prolong its life, and help you obtain optimum performance. Please read this normal care schedule, and note the recommended care operating intervals to extend the life of your unit.
OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Change Forward/Reverse Belt! Turn off engine. Engine must be cool. Remove spark plug wire and secure from spark plug. Remove belt guard. Do not operate tiller before reading the engine manual provided in the parts packet. remove the forward belt from the forward engine pulley: - gently pull the engine recoil rope to rotate the pulley.
with the pulley turning, force the forward belt out of the V-groove. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Engine Maintenance Refer to the engine manual included in your parts packet for information on engine maintenance. Your engine manual provides detailed information and a maintenance schedule for performing the following tasks: 1. Check oil level before each use or after every 8 hours of operation. Change oil after first 5-8 hours of operation.
Change oil while engine is warm. Refill with new oil of recommended grade. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Lubrication Proper lubrication of moving mechanical parts is critical for proper care and maintenance. Oil the moving parts at 10 hour intervals using a 30 weight oil.
Clean Tine Axle Shaft 1. Turn off engine. Engine must be cool. Remove spark plug wire and secure from spark plug.!
WARNING Do not store tiller in an unventilated area where fuel fumes may reach flame, sparks, pilot lights or an ignited object. OPERATor INSTRUCTIONS and parts SRT Models 7055 & 7065V Troubleshooting! WARNING Troubleshooting Guide Practice safety at all times. Engine must be turned off and allowed to cool, and spark plug wire must be disconnected and secured before attempting any maintenance or repair. While normal care and routine maintenance will extend the life of your rototiller, prolonged or constant use may eventually require that service be performed to allow it to continue operating properly.
